High Current Ideal Diode Module 100V 300A Solar Anti-reverse Charging Anti-Reverse Current Protection
Specification:
Item Type: Diode
Material: Aluminum plate
Working Voltage: 30-100V
Working Current: Maximum working current 300A
Circuit Board Size: Approx. 140 x 95mm/5.5 x 3.74inch
Copper Foil Thickness: 3.0oz
Purpose: Replace ordinary high-current diodes, ideal for parallel connection of solar panels, suitable for charging anti-backflow protection
How to Use:
1. Unscrew the screws before wiring
2. According to the signs on the board, positive input and positive output
3. Wrap the wire in the middle of the screw gasket and tighten the screw
4. Or use clips to directly clamp the copper sheet
The characteristics of an ideal diode are that the forward conduction voltage is 0V, the reverse leakage is 0A, and the reverse cutoff time is 0µs. When an ordinary diode is close to ideal, it has lower power consumption and smaller temperature rise when it is forward-conducting. When it is reverse-cutoff, it can achieve lower leakage and longer life. Of course, there is no absolutely ideal diode, but a diode that makes the three indicators closer to 0 can be called an ideal diode.
|
Enerkey Ideal Diode Module 40V 80V 100V 150V 300A Photovoltaic Solar Base Station Industrial Control Electric Car Battery in Parallel For Battery charging anti-backfilling
|
||||
| Product model |
EK-iD40V300A |
EK-iD80V300A |
EK-iD100V300A |
EK-iD150V300A |
|
Working voltage range
|
30-40V
|
30-80V
|
30-100V |
30-150V
|
|
Product Size(mm)
|
L140xW95XT32.5
|
L140xW95XT32.5 | L140xW95XT32.5 |
L140xW95XT32.5 |
|
Weight with box
|
0.6kg
|
0.62kg
|
0.64kg |
0.68kg
|
| MOS quantity | 2 | 2 | 2 | 2 |
|
Battery Type
|
NCM/LFP/LTO
|
NCM/LFP/LTO | NCM/LFP/LTO |
NCM/LFP/LTO
|
|
Continuous current
|
300A
|
300A | 300A | 300A |
| Peak starting current | 300A | 300A | 300A | 300A |
|
Quiescent operating current
|
0.6-1.5mA
|
|||
|
Copper foil thickness
|
3.0 oz
|
|||
|
PCB material |
Aluminum plate
|
|||
| On-going internal resistance | NA | |||
| Working principle | The input and output are equivalent to diodes. It detects that the output voltage is greater than the input and immediately turns off the output. The detection value is at the millivolt level and the response speed is very fast. | |||
|
Application
|
1. Solar panels prevent backflow (anti-backflow);
2. Battery charging prevents backflow (anti-backflow) (anti-backflow); 3. DC-DC constant voltage and constant current module output prevents backflow 4. Other occasions where backflow prevention (anti-backflow) is required |
|||
| Accessories | Terminal lug*3; IN+/OUT+ terminal lug : OTZ50-8, screw M8 GND terminal lug : OTZ2.5-3, screw M3 |
|||
|
Operating Temperature
|
-40℃ ~ +60℃
|
|||
Special Note:
1. This version is the latest optimized version. If the positive and negative poles are connected reversely, the module will not be burned, which improves the safety of installation;
2. An ideal diode is a diode with ultra-low internal resistance as the name implies. The conduction voltage drop of an ordinary diode is more than 0.6V.
The conduction voltage drop of an ideal diode is almost negligible.
3. The copper foil layer and aluminum base layer of the aluminum substrate PCB trace are insulated with a withstand voltage of 1000V, so there is no need to worry about breakdown problems.
Thermal conductivity is 20 times faster than FR4 glass fiber and can be directly attached to large heat sinks.
4. This ideal diode module cannot be used in rectifier circuits!
