| Brand Name: | ENERKEY |
| Model Number: | JW-8S15A-799 |
| MOQ: | 2 pieces |
| Price: | $34.00/pieces 2-999 pieces |
| Packaging Details: | Carton |
|
Electric Parameter
|
|
|
|
|
|
|
||||||
|
NO.
|
Project
|
|
Min.
|
Typ.
|
Max.
|
Unit
|
||||||
|
1
|
Parameter
|
Charging voltage
|
|
|
28.8
|
V
|
||||||
|
|
|
Working current
|
|
|
15
|
A
|
||||||
|
|
|
Usage(Li-ion battery packs)
|
|
29.6
|
|
V
|
||||||
|
|
|
Usage(LiFePO4 battery packs)
|
|
25.6
|
|
V
|
||||||
|
|
|
Balance voltage for single cell
|
|
3.6
|
|
V
|
||||||
|
|
|
Balance current for single cell
|
30
|
40
|
50
|
mA
|
||||||
|
2
|
Overcharge protection
|
Overcharge detection voltage for single cell
|
3.625
|
3.65
|
3.675
|
V
|
||||||
|
|
|
Overcharge detection delay time
|
800
|
/
|
1300
|
mS
|
||||||
|
|
|
Overcharge release voltage for single cell
|
3.40
|
3.45
|
3.50
|
V
|
||||||
|
3
|
Overdischarge protection
|
Overdischarge detection voltage for single cell
|
2.15
|
2.20
|
2.25
|
V
|
||||||
|
|
|
Overdischarge detection delay time
|
800
|
/
|
1300
|
mS
|
||||||
|
|
|
Overdischarge release voltage for single cell
|
2.3
|
2.4
|
2.5
|
V
|
||||||
|
4
|
Overcurrent protection
|
Over discharge current protection
|
65
|
85
|
105
|
A
|
||||||
|
|
|
Detection delay time 1
|
500
|
/
|
1500
|
mS
|
||||||
|
|
|
Detection delay time 2
|
500
|
/
|
1500
|
mS
|
||||||
|
|
|
Overcharge current protects current
|
/
|
/
|
/
|
A
|
||||||
|
|
|
Detection delay time
|
/
|
/
|
/
|
mS
|
||||||
|
5
|
Short-circuit protection
|
Short-circuit protection current
|
|
300
|
|
A
|
||||||
|
|
|
Short-circuit detection delay time
|
50
|
/
|
800
|
μS
|
||||||
|
|
|
Protection condition
|
Exterior short circuit
|
|
|
|
||||||
|
|
|
Release condition
|
Cut load
|
|
|
|
||||||
|
|
|
MOSMOS temperature protection
|
/
|
/
|
/
|
℃
|
||||||
|
|
|
Charge high temperature protection
|
50
|
55
|
60
|
℃
|
||||||
|
|
|
Charge low temperature protection
|
/
|
-5
|
/
|
℃
|
||||||
|
|
|
Discharge high temperature protection
|
65
|
70
|
75
|
℃
|
||||||
|
|
|
Discharge low temperature protection
|
-5
|
-10
|
-15
|
℃
|
||||||
|
|
|
Release condition
|
The temperature drops to 50ºC, charge release
|
|
|
|
||||||
|
|
|
Operating temperature range
|
-20
|
/
|
60
|
℃
|
||||||
|
|
|
Storage temperature range
|
-20
|
/
|
60
|
℃
|
||||||
|
7
|
Current
|
Current consumption
|
|
|
70
|
uA
|
||||||
|
|
|
Maximal continuous charging current
|
|
|
15
|
A
|
||||||
|
|
|
Maximal continuous discharging current
|
|
|
15
|
A
|
||||||
|
|
|
Maximal discharging current (time)
|
None
|
|
|
|
||||||
|
7
|
Resistance
|
The on-state resistance of the main circuit
|
/
|
/
|
20
|
mΩ
|
||||||
|
8
|
Break circuit protection
|
Disconnect the voltage sampling circuit to turn off the charge and discharge
|
Support
|
|
|
/
|
||||||
|
9
|
NTC Protection
|
Thermistor temperature protection
|
Support
|
|
|
/
|
||||||
|
10
|
Electronic switch
|
|
Nonsupport
|
|
|
/
|
||||||
|
11
|
Reverse polarity protection
|
|
Nonsupport
|
|
|
/
|
||||||
|
|
