| Brand Name: | ENERKEY |
| Model Number: | JW-B1S10A-359 |
| MOQ: | 50 pieces |
| Price: | $2.15/pieces 50-99 pieces |
| Packaging Details: | Carton |
A LiFePO4 BMS controls the discharge and charge processes of LiFePO4 battery packs. So if anything goes wrong during these processes, the BMS protection immediately kicks in and adjusts the charging parameters or cuts off the power flowing to and from the battery pack entirely.
Moreover, a BMS monitors the battery cells and makes sure they’re all working together correctly. It also measures parameters like voltage, current, and temperature to ensure that the battery is healthy and safe.
|
Electric Parameter
|
|
|
|
|
|
|
||||||
|
PCM Specifications For 3.7V(1S)Li-ion Battery Packs
|
|
|
|
|
|
|
||||||
|
Model:JW-B1S10A-359
|
|
|
|
|
|
|
||||||
|
NO.
|
Project
|
|
Min.
|
Typ.
|
Max.
|
Unit
|
||||||
|
1
|
voltage
|
Charging voltage
|
|
4.2
|
|
V
|
||||||
|
|
|
Balance voltage for single cell
|
/
|
/
|
/
|
V
|
||||||
|
2
|
Current
|
Balance current for single cell
|
|
|
/
|
mA
|
||||||
|
|
|
Current consumption
|
|
|
15
|
uA
|
||||||
|
|
|
Maximal continuous charging current
|
|
|
10
|
A
|
||||||
|
|
|
Maximal continuous discharging current
|
|
|
10
|
A
|
||||||
|
3
|
Over charge protection
|
Overcharge detection voltage for single cell
|
4.300
|
4.325
|
4.350
|
A
|
||||||
|
|
|
Overcharge detection delay time
|
0.7
|
|
1.3
|
S
|
||||||
|
|
|
Overcharge release voltage for single cell
|
4.00
|
4.05
|
4.10
|
V
|
||||||
|
4
|
Over discharge protection
|
Overdischarge detection voltage for single cell
|
3.438
|
3.50
|
3.562
|
V
|
||||||
|
|
|
Overdischarge detection delay time
|
14
|
|
26
|
mS
|
||||||
|
|
|
Overdischarge release voltage for single cell
|
3.4
|
3.5
|
3.6
|
V
|
||||||
|
5
|
Overcurrent protection
|
Over current detection voltage
|
0.18
|
0.2
|
0.22
|
V
|
||||||
|
|
|
Over current detection current
|
17
|
20
|
23
|
A
|
||||||
|
|
|
Detection delay time
|
8
|
|
16
|
mS
|
||||||
|
|
|
Release condition
|
Cut load
|
|
|
|
||||||
|
6
|
Short protection
|
Detection condition
|
Exterior short circuit
|
|
|
|
||||||
|
|
|
Detection delay time
|
200
|
|
500
|
μS
|
||||||
|
|
|
Release condition
|
Cut load
|
|
|
|
||||||
|
7
|
Resistance
|
Protection circuitry (MOSFET)
|
|
|
50
|
mΩ
|
||||||
|
8
|
Temperature
|
Operating Temperature Range
|
-40
|
|
85
|
℃
|
||||||
|
|
|
Storage Temperature Range
|
-40
|
|
125
|
℃
|
||||||
|
|
