Active Equalizer
>
Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage

Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage

Brand Name: Enerkey
Model Number: EK-C5S5A
MOQ: 60 pieces
Price: $6.84-$8.96
Packaging Details: Strong paper box +EVA Foam
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
Shenzhen, China
Certification:
ISO9001/CE/ROHS
Product Name:
5S 5A Active Equalizer For Lithium Battery
Copper Thickness:
2oz
Application:
Commercial Energy Storage, Industrial Energy Storage
Board Thickness:
1.6mm
Battery Type:
NCM / LFP/ LTO
Battery Strings:
4s-5s
Base Material:
FR-4
Surface Finishing:
Lead-free HASL
Keywords:
Capacitive Active Balancer
Usage:
Li-ion/Lifepo4/Lto Battery Pack
Product Size:
L69*W58*T16mm
Weight With Package:
0.15kg
Supply Ability:
1000000pcs per day
Highlight:

Lifepo4 Battery active balancer

,

5a Lifepo4 Battery Equalizer

,

Commercial Energy Storage active balancer

Product Description
Product Description

With the rapid development of battery products, the importance of battery balancing technology is also increasing day by day. For energy storage batteries, battery balancing technology can improve their overall performance, extend service life,

enhance system reliability, optimize energy management, reduce operation and maintenance costs, and promote environmental protection and resource recycling.
However, in the earliest days, before the emergence of battery balancing technology, the inconsistency problem of battery packs was mainly solved by design redundancy, but this is not an efficient method. And with the popularization of lithium-ion batteries,

especially for application scenarios that require high energy density, the consistency problem of battery packs has become one of the problems that must be solved.



Therefore, engineers began to introduce simple resistors in battery packs as a means of balancing. When the voltage of a battery cell exceeds the preset value, the excess power will be consumed through the resistor. This method is called passive balancing.

Although this method has a simple structure and is easy to implement, it is inefficient because it only converts excess power into heat energy and dissipates it instead of effectively reusing it.

In order to solve the problem of inefficiency, active balancing technology began to emerge, which can transfer the energy of high-voltage battery cells to low-voltage battery cells instead of simply consuming it.



Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 0

Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 1

Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 2

Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 3

Balancing Extends LiFePO4 Battery Life
LiFePO4 battery balancing does extend its life significantly. In fact, if you follow a proper balancing process regularly, you can extend the lifespan of your battery far beyond what manufacturer-rated lifespan. This is not limited to the Lithium Iron Phosphate battery pack. It also applies to many other types of batteries.



Technical Parameters



EnerKey BMS Active Balancer 5A 3S 4S 5S 6S 7S 8S 14S 16S 18S 19S 20S 21S LFP LTO LI-ION lifepo4 Balancer Capacitor Balancer
Product strings
3S
4S
5S
Suitable strings
3S
3-4S
4-5S
Product Size(mm)
L66*W35*T16
L66*W46*T16
L69*W58*T16
Weight with box
0.12kg
0.13kg
0.15kg
Battery Type
NCM/LFP
NCM/LFP
NCM/LFP/LTO
Suitable capacity
30ah-300ah
Balanced Cascading
Support balanced cascading for battery packs, for example , it can cascade for 11S , 24S ,36S , 48S....and so on
Single cell voltage collection range
NCM/LFP version : 2.7V-4.2V
LTO version : 1.8-4.2V
Undervoltage protects sleep voltage
NCM/LFP version<2.7V
LTO version<1.8V
Equilibrium method
Patented (Patent No.: ZL 2019 1 1259513.3) balanced architecture Fit capacitor method, the entire battery pack is balanced at the same time.
Connect to the battery pack for automatic balancing (default). You can add a switch to manually turn on or off balancing.
Equilibrium current
0.1V Differential pressure 1A Balanced current,
the differential pressure is proportional to the balanced current,
the maximum allowable operating current is 5.5A
Voltage equalization accuracy
5mV (typical value)
External power supply
No need for an external power supply,
relying on the internal energy transfer of the battery to achieve sdjacent equalization.
Quiescent operating current 7mA, the total string draws power
Sleep standby current
0.1mA(typical value)
Operating Temperature
-20℃ ~ +60℃



Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 4



Packing List

Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 5

 Wire connect

A single EK-C5S5A supports the use of 4 and 5 string battery packs. The wiring method is as follows:

Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 6
Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 7

EK-C5S5A supports cascading battery packs. Fox exmple, 2pcs of 5s cascade to 9s, see below drawing:

Enerkey 5s active balancer 5a Lifepo4 Battery Equalizer For Commercial Energy Storage 8

NOTE:As shown in the figure above,there can be multiple common ends of energy exchangeso that the efficiency of equilibrium will be higher;It is also possible to use only one common end of theenergy exchange atthejunction of two modules.The other free feet are suspended, and it is best todistribute the number of strings equally on each board.If you need the cascade diagram for more strings, Please contact our online service, Thanks.

 FAQ



Q1. Why did we choose you?

* We can provide you with efficient after-sales service, with more than 10 years of strong technical support.

* Products have passed FCC, CE, ROHS and other international standards certification.

* We can provide you with factory price, Welcome you to visit our factory and production process.



Q2. What is your product range (type)?

*We mainly do battery management systems in the fields of power batteries, energy storage batteries and consumer batteries.

*Mainly used for LFP, Li-ino and LTO batteries.



Q3: How do I know which kind of material & type my battery is ?

*Please look the battery body, If the normal voltage of your battery shows 3.2V, The battery is LiFePo4.

*If the normal voltage of your battery shows 3.6V or 3.7V, the battery is Li-ion or Lto battery.



Q4. Do you have minimum order requirements?

Can it be customized? What is the lead time for samples and batches?

*Our minimum order quantity is 1 piece, ODM customization is available.

* 1~3 days delivery of existing samples, 3~10 days delivery of customized samples.



Q5: What if i can't use it?

*Regular products have instructional videos, We can also support online video call guidance from engineers.



Q6. What are your terms of payment?

*We accept wire transfer and cash payment, all negotiable. Payment method :visa, mastercard, T/T, PayPal, APPLE_PAY, GOOGLE_PAY, GC_REAL_TIME_BANK_TRANSFER, RMB



Q7. How do you guarantee the quality?

* All our products are subjected to professional laboratory 100% testing, as well as repeated aging tests.

* Obtained FCC, CE, ROHS and other international standard certification.

* Provide 3 years after-sales warranty service. Free spare units for replace in 3 years.



Q8. How to choose a BMS suitable for our battery?

*Depending on the voltage and current that matches your battery, you can consult our customer service and we will provide it for you equipped with the most suitable battery management system.



Q9. How can i contact you?

*We have 7x24 hours online service, Please leave us a message online.

*You can also contact us by Email, WhatsApp, WeChat, etc(see below). We are so glad to work with you.



Noted: We are source manufacturer, We have own brand for "EnerKey",We can customized product as your requirement(Voltage, Wire,Etc) .
We can provide you competitive price in the market if you have bulk order, Please don't hesitate to contact us.
Mobile & WhatsApp & Wechat: +86 15387469240; Email: kiwi@enerkey.cn
